1000va 1000w Modified Sine Wave Power Inverter MPPT Solar Photovoltaic Inverter 12v To 220v
What is feature of 1000va 1000w modified sine wave power inverter MPPT solar photovoltaic inverter 12v To 220v ?
1.Built-in PWM/MPPT solar controller
2.Modified sine waveform output 12V 1000VA/1500VA
3.Big LED display screen
4.This series is to control the inverter machine,the external battery is more convenient,flexible according to the needs of customers
5.This series of system cover home system 100W to 1000W power,is the preferred choice of high lift configuration system
6.DC output:12V(24V),5V,LED lamp with a camera,mobile phone charging
>>>Product Specifications
| Model | SUS-1000AL+PWM |
| Solar controller | 12V/10A PWM |
| Solar panel | 500-600W/50V |
| External battery | 12V |
| USB output | 5V 1A |
| Output USB interface | 5.0+/-0.3V |
| Output voltage | AC 220V+/-5% |
| Rated output power | 600W |
| Peak power | 1000A |
| No load current | <0.5A |
| DC input voltage | DC9.7V-15.5V |
| Output frequency | 50Hz±3Hz |
| Conversion efficiency | 70%-80% |
| High voltage cut-off protection | 15V±0.5V |
| Low voltage alarm | 11.2V±0.3V |
| Low voltage cut-off protection | 10V±0.3V |
| Overload/short circuit protection | Yes |
| Output waveform | Modified sine waveform |
| Cooling mode | Cooling fan |
| Operating temperature | -20°C~+70°℃ |
| Relative humidity | <90%RH |
TV, display and motor's electric quantity would reach peak value at the moment they turn on. Although the converter could support the peak power that is two times of nominal power, some AC products whose power meet requirement would exceed the peak output power of the inverter. It would cause overload protection and current would be cut. When you charge for more than one AC product, this situation would happen. So you should turn off the AC product and turn on the switch power supply and turn on the power supply one by one. You had better turn on the AC product whose peak value is the highest one first.
Vehicle should be started timely and charge for the battery to prevent power's failure and affect auto start and battery life. Despite the converter is equipped with overload protection function, when the input voltage is over 16V/30V, converter may still be damaged. After continuous use, surface temperature of the shell will rise to 60 degrees.
