2000 Watt Pure Sine Wave Inverter With Max 60A 2-Channel MPPT Solar Charger
This advanced 2000 Watt Pure Sine Wave Inverter with Max 60A 2-Channel MPPT Solar Charger provides reliable power conversion and solar charging capabilities for various applications.
External Battery Support: Designed for external 12V/24V battery systems, offering flexible and reliable power supply without built-in battery limitations.
Wide Solar Input Range: Accepts solar panel input of 100-150V (for 12V system) or 200-300V (for 24V system), compatible with multiple PV configurations.
High Power Output: Delivers up to 1500W continuous power and 3000W peak power, suitable for running high-load appliances like refrigerators or small air conditioners.
Pure Sine Wave AC Output: Provides clean 220V/50Hz pure sine wave output, safe for sensitive electronics such as TVs, computers, and medical devices.
Smart Protection System: Equipped with over-voltage, under-voltage, over-load, short-circuit, over-heat, and reverse polarity protection for device and battery safety.
Multi-Function Display & Monitoring: Features a digital display showing real-time output voltage, battery voltage, and fault codes (PV/CHG/PFAULT) for easy system monitoring and troubleshooting.
| Model | SMS-1000A+MPPT | SMS-1000B+MPPT | SMS-1500A+MPPT | SMS-1500B+MPPT |
|---|---|---|---|---|
| The built-in controller | 25A-30A | 20A-25A | 50A-60A | 50A-60A |
| Featured solar panel specifications | 100~200W/36Vx2 | 200~300W/36Vx2 | 100~150W/36Vx4 | 100~150W/36Vx4 |
| External battery | 12V 100Ah~150Ah | 24V 100Ah~150Ah | 12V 100Ah~150Ah | 24V 100Ah~150Ah |
| Output voltage of the inverter | AC 220V+/-5% | AC 220V+/-5% | AC 220V +/-5% | AC 220V +/-5% |
| Maximum continuous power | 1000W | 1000W | 1500W | 1500W |
| Peak power | 2000W | 2000W | 3000W | 3000W |
| No load current | <0.5A | <0.3A | <0.5A | <0.3A |
| DC input voltage | DC9.7V~15.5V | DC20V~32V | DC9.7V~15.5V | DC20V~32V |
| Output frequency | 50+/-3Hz | 50+/-3Hz | 50+/-3Hz | 50+/-3Hz |
| Conversion efficiency | >90% | >90% | >90% | >90% |
| High pressure cut off | 15V+/-0.5V | 31V+/-0.5V | 15V+/-0.5V | 31V+/-0.5V |
| Low voltage alarm | 11.2V+/-0.3V | 22V+/-0.3V | 11.2V+/-0.3V | 22V+/-0.3V |
| Low cut | 10V+/-0.3V | 20V+/-0.3V | 10V+/-0.3V | 20V+/-0.3V |
| Overload, short circuit protection | There are | There are | There are | There are |
| Output waveform | Fixed wave | Fixed wave | Fixed wave | Fixed wave |
| Cooling mode | Fan cooled | Fan cooled | Fan cooled | Fan cooled |
| Working environment temperature | -20℃~+70℃ | -20℃~+70℃ | -20℃~+70℃ | -20℃~+70℃ |
| Relative humidity | <90%RH | <90%RH | <90%RH | <90%RH |
